JP8B

JP8B 8" JOINTER WITH CLOSE STAND
Main Features

Main Features:

*  Precision-ground cast-iron tables with dovetailed ways

*  New quick adjusting handle for table's easy rapid rise and fall

*  Quick locking function for easy and steady fixing of the table position

*  Heavy-duty cast iron fence with precision-ground

*  Fence Tilts  45°~ 90°

*  Professional protection guard

*  Cabinet stand

Description Video Documents

01)    Description: 8-inch jointer

02)    Motor: 2,200W

03)    Table size: 1780x230mm

04)    Fence size: 1018x125mm

05)    Cutter Block dia:72mm

06)    Cutting knives: three

07)    Fence tilt: 0 to 45 degrees

08)    Dust chute diameter: 100mm

09)    Maximum planing width: 204mm

10)    Maximum cutting depth: 12.7mm

11)    Rabbeting:13X15mm

12)    Cutter block speed(50HZ): 4,500rpm

13)    Push Blocks:2pcs

14)    Overall size:1800X630X1250mm

15)    Packing size(machine): 1800x650x410mm;570x480x650mm

16)    N/G Weight:197/215kgs

17)    Units/20'container:64
