Main Features

* Quick and easy sanding belt replacement

* Easy and quick grinding angle setting

* Easy and quick change of grinding tools

* Quick change of head position in the vertical-horizontal range

* Optional for single speed or two speeds

Description Video Documents

Universal belt grinder with extensive standard equipment and the ability to work vertically and horizontally.

1) Motor power: 3kw(single speed);  1.5 kW / 2.2 kW(two speeds)

2) Sanding Belt Speed: 19m/s(single speed);19/29m/s(two speeds)

3) Sanding Belt Dimension: 75 x 2000 mm

4) Rubberized wheel dia: 200 mm

5) Tool with sliding support and rollers:120 x 90 mm

6) Pipe grinding vice with adjustable angle: 0-30°

7) Rollers sets: 19; 21.5; 27; 34; 42; 48; 60 mm

8) N/G Weight: 110/125 kg

9) Packing size:740x658x1090 mm

Optional for 400V 2speeds Type with model number SDM75 II
