* New designed fence structure that can display the angle ruler.
* Two front handles for opening planner tables and the eccentric locking. Fast and easy change over from planing to thicknessing.
* New switch box with Emergency stop
* Two removable screws for lifting machines by the pallet truck: one fork under the machine and one fork under the screws.
* Fitted with extension table on both of the thicknessing tables.
* Fitted with super high quality HSS blades as standard.
* Fitted with cast iron handwheel + ML39-DR mechanical digital display for thicknessing height.
This 16" planer&thicknesser is designed and built to withstand heavy use on a daily basis in any professional workshop. Designed with two front handles for opening planner tables and the eccentric locking, it's fast and easy change over from planing to thicknessing. The thicknessing table adjusts smoothly by cast iron handwheel and a mechanical digital height indicator allows for accurate measurement of the cut. New designed fence structure that can display the angle ruler. Extension table on both of the thicknessing tables for better support.
Specifications:
01)Motor power: 3KW,Optional:3.5KW,4KW(400V)
02)Motor speed: 2850rpm
03)Max. planing width: 410mm
04)Max planing depth: 3.5mm
05)Cutter block speed: 4500rpm
06)Number of cutting knives: 3
07)Fence tilt: 0°-45°
08)Planer table size: 1680x416mm
09)Cutter block diameter: 75mm
10)Feeding block diameter: 32mm
11)Thicknessing table size: 600x408mm
12)Max. thicknessing width: 408mm
13)Max. thicknessing depth: 4.5mm
14)Feed speed: 5.4 m/min
15)Max. thicknessing height: 230mm
16)Dust chute port: 100mm
17)Mortising Max tool diameter: 16mm
18)Mortising Max mortising depth: 80mm
19)Mortising Lateral stroke: 140mm
20)Mortising Vertical stroke: 85mm
21)Packing size: 1700X760X1060mm
22)N.G. weight without mortiser: 260kgs
23)N.G. weight with mortiser: 282kgs
24)Units/20'container: 20pcs
