CK-4Z/S1

4" 4 JAW KEY SELF-CENTERING CHUCK SET 1X8"TPI INCLUDING SIX SETS JAWS, 5/8" AND 1" QUICK CHANGE CROWN CENTER, 1"X8TPI AND M33X3.5 ADAPTOR, SCREW CHUCK, T HANDLE ALLEN KEY, CHUCK KEY IN BLACK BLOW MOULD CASE
Main Features

This chuck set contains

01. Round jaws with Clamping range 45-73mm, Support range 60-88mm

02. Step jaws with Clamping range 3-31mm, Support range 25-80mm

03. O' Donnell jaws with Clamping range 3-31mm, Support range 25-80mm

04. Dovetail pin jaws with Support range 30-58mm

05. Dovetail wide jaws with Clamping range 92-120mm, Support range 110-138mm

06. 10" Aluminum flat jaws with Clamping range 49-236mm,Support range 97-287mm

07. 5/8" and 1" Qucik change crown center

08. 1"X8TPI and M33X3.5 Adaptor

09. Screw chuck

10. T handle allen key

11. Chuck key

12. 8 PCS Taper screw


Packing size: 36x34x26cm

N.W./G.W.:28.2/32.7KGS

QTY/CTN:4 PCS


Description Video Documents

This chuck set contains

01. Round jaws with Clamping range 45-73mm, Support range 60-88mm

02. Step jaws with Clamping range 3-31mm, Support range 25-80mm

03. O' Donnell jaws with Clamping range 3-31mm, Support range 25-80mm

04. Dovetail pin jaws with Support range 30-58mm

05. Dovetail wide jaws with Clamping range 92-120mm, Support range 110-138mm

06. 10" Aluminum flat jaws with Clamping range 49-236mm,Support range 97-287mm

07. 5/8" and 1" Qucik change crown center

08. 1"X8TPI and M33X3.5 Adaptor

09. Screw chuck

10. T handle allen key

11. Chuck key

12. 8 PCS Taper screw
