FM300S

3hp Dust Collector With 500mm Bag Diameter
Main Features
Description Video Documents

01)  Motor: 2,200W

02)  Fan diameter: 305mm

03)  Inlet diameter: 150mm

04)  Number of intake holes: 3 x 100

05)  Air speed-50Hz: 2,300CFM/65.09cubic meter/min

06)  Air speed-60Hz: 2,760CFM/78.11cubic meter/min

07)  Bag diameter: 500mm

08)  Collection bag height: 1000mm(plastic bag as standard)

09)  Bag volume: 0.307cubic meter

10)   Overall LxWxH: 1450x800x2000mm

11)  Net/gross weight: 52/57kg

12)  Packing size: 1,170x560x570mm

13)  Units per 20-foot container: 80


* With Polyester fiber material filter bag on the top + plastic collection bag on the bottom fitted as standard fitting.
