FM270H

FM270H 1.5HP DUST COLLECTOR WITH STEEL TUBE STANDS
Main Features
* The machine body with motor unit can be assembled upside down or up in two ways for use with a wall mounted extraction system or as standard dust collector.
* With Polyester fiber material filter bag on the top + plastic collection bag on the bottom fitted as standard fitting.
* With cartridge filter CF1424 available as optional


Description Video Documents

01)   Motor Power: 1100W
02)   Fan diameter: 268mm
03)   Inlet diameter: 100mm
04)   Number of intake holes: 1 x 100
05)   Air speed: 588CFM/16.7m3/min
06)   Filter bag size: 340mm dia x820mm height
07)   FFilter bag area:0.966m2
08)   Collection bag size:340mm dia x908mm height
09)   Collection bag volume:0.0824M3
10)   Overall size:822X460X1850 mm
11)   Packing size: 830 x 460 x 510mm
12)   Net/gross weight: 29.5/33kg
13)   Units per 20-foot container: 140
