FM270

FM270 1.5HP DUST COLLECTOR WITH 340MM BAG DIAMETER
Main Features

* The machine body with motor unit can be assembled upside down or up in two ways for use with a wall mounted extraction system or as standard dust collector.
* With Polyester fiber material filter bag on the top + plastic collection bag on the bottom fitted as standard fitting.
* With cartridge filter CF1424 available as optional


Description Video Documents

Specifications:
01)  Motor Power: 1100W
02)  Fan diameter: 268mm
03)  Inlet diameter: 100mm
04)  Number of intake holes: 1 x 100
05)  Air speed: 900CFM / 25.50M3/MIN
06)  Filter bag size: 340mm dia x820mm height
07)  Filter bag area:0.966m2
08)  Collection bag size:340mm dia x908mm height
09)  Collection bag volume:0.0824M3
10)  Overall size:1814x715x396mm
11)  Packing size: 815 x 450 x 450mm
12)  Net/gross weight: 31.5/35kg
13)  Units per 20-foot container: 175
