FM230L5RA

FM230-L1 1HP DUST COLLECTOR WITH 370MM BAG DIAMETER WITH 15" CARTRIGE FILTER + REMOTE CONTROL
Main Features

MAIN FEATURES:

* Large rubber wheels enable convenient and flexible movement.

* Solid and stable machine body, and equipped with a standard cartridge filter.

* Equipped with a remote control switch.


Description Video Documents

Specifications:

01) Motor speed (rpm)/50Hz: 2850r/min

02) Motor speed (rpm)/60Hz: 3450r/min

03) Impeller diameter (mm): Ф230

04) Air inlet Diameter (mm): Φ100

05) Number and diameter of suction (mm): 1×Φ100

06) Cartridge Filter area (m2): 3

07) Cartridge Filter capacity (micro):1

08) Dust bag Size (mm): Φ370×640

09) Dust bag volume (m3): 0.057

10) Negative pressure (kpa)/50Hz: 1.08

11) Negative pressure (kpa)/60Hz: 1.5

12) Air volume (m3/h)/50Hz: 451

13) Air volume (m3/h)/60Hz: 610

14) Noise (dB): 77

15) Overall dimensions (mm): 826X515X1470

16) Package size (mm): 772X450X495+620X400X400

17) N/G weight (kg): 30.5/32.5KG+6/8KG

18) Quantity of 20' containers: 113pcs


* With cartridge filter on the top + plastic collection bag on the bottom fitted as standard fitting.
