ZQJ4113C

8" OSCILLATING DRILL PRESS WITH 350W MOTOR
Main Features

* Can be used for efficient contour sanding in addition to traditional drilling, both a drill press and an oscillating sander in one compact machine

* Fitted with a 1.5-13mm B16/JT33 keyed drill chuck, offers up to 50mm of travel and a drilling capacity of 13mm.

* With the oscillating feature, the oscillating stroke length is 19mm

* The 180x170mm table allows for drilling and surface sanding at different angles as it tilts 90° in both directions.

* The table has a clearance hole for use while sanding, by incorporating a 52mm dust collection port

* A sanding drum shaft (dia 12mm,length 110mm) is included as standard

* Not for use with a mortising attachment or mortising bits.


Description Video Documents

01)  Motor: 350W

02)  Swing: 218mm

03)  Chuck size: 1.5-13mm

04)  Maximum drilling capacity: 13mm

05)  Taper: B16

06)  Spindle travel: 50mm

07)  Five levels of speed

08)  Speed range (rpm)/50Hz: 600 to 2,500

09)  Speed range (rpm)/60Hz: 620 to 3,100

10)  Overall height: 575mm

11)   Column diameter: 40mm,Collar diameter: 40mm,Quill diameter: 40mm

12)   Working table: 180*170mm

13)  Packing size: 460 x 360 x 270mm

14)  Net/gross weight: 20/21kgs

15)  Units per 20-foot container: 640
