* Suitable for sanding of wood, plastics and similar materials
* Oscillating sanding belt guarantees generous removal of material and smooth finish
* Dust port on both sides (80 / 120 mm) for optimal dust removal
* Oscillation of sanding belt with separate drive motor can be switched on
* Spring balanced belt tension allows automatic adjustment of differences in sanding belt lengths
* Handwheel ensures user-friendly height adjustment of work table
* Torsion-free, steel-plate machine base eliminates vibrations
* Cast iron handwheel optional
01) Main table size: 960x350mm
02) Table height adjustment：210 mm
03) Supporting work table:330x330
04) Belt length：3000 mm
05) Belt width：150 mm
06) Sanding table：1050 x 200 mm
07) Tilting of sanding unit：90° - 45°
08) Belt speed：20 m/sec
09) Oscillation motor：0,25 kW (0,34 HP)
10) Oscillation stroke：20 mm
11) Dust hood diam.：120 mm
12) Motor：3,0 kW (4,0 HP)
13) Overall dimension：1900 x 840 x 1020 mm
14) Packing size:1540x770x1150mm
15) N/G Weight.：290/357 kg
16) Units/20'container:14
Standard accessories:
Sanding belt oscillation; Sanding belt 3000 x 150 mm - grit 100; Support table; Graphite coating; Mitre fence; Tube
Optional parts:
* Cast iron handwheel optional
