* Cast iron upper and lower wheels with braking motor fitted for prefect working performance
* Parallel fence with micro adjustment function and double reading by magnifier to position 2 sides of the blade of saw and so adapt itself to all the cuttings.
* Three windows to show the saw blade tension and running positions
* Big size working table area 730x480mm totally for prefect preformance.
* Arc shape doors for modern appearance
* Additional fence for thin piece facilitates you the access and the holding of your pieces of samll widths.
* Quick clamping lever and blade tension adjustment on the back of the machine.
01) motor in 230V:3HP
02) motor in 400V:3HP
03) saw blade size:3607x12.5~38.1mm
04) saw blade speed:14;7m/s
05) table size:630x480mm
06) extension table size:100x480mm(optional)
07) table tilt:-10~45degree
08) wheel diameter:470mm
09) cutting width:465mm
10) cutting depth:280mm
11) new/gross weight:162/180kgs
12) packing size:826x545x2070mm
13) units per 20-feet container::28sets
