HBS410P

DELUX 16" WOODWORING BANDSAW
Main Features

*Cast iron upper and lower wheels with braking motor fitted for prefect working performance
* Parallel fence with micro adjustment function and double reading by magnifier to position 2 sides of the blade of saw and so adapt itself to all the cuttings.
* Three windows to show the saw blade tension and running positions
*Big size working table area 660x450mm totally for prefect preformance.
* Arc shape doors for modern appearance
* Additional fence for thin piece facilitates you the access and the holding of your pieces of samll widths.
* Quick clamping lever and blade tension adjustment on the back of the machine.


Description Video Documents

01)   motor in 230V:3HP
02)   motor in 400V:3HP
03)   saw blade size:3345x9.5~38.1mm
04)   saw blade speed:14;7m/s
05)   table size:560x450mm
06)   extension table size:100x450mm (optional)
07)   table tilt:0~45degree
08)   wheel diameter:420mm
09)   cutting width:410mm
10)   cutting depth:250mm
11)   new/gross weight:126/140kgs
12)   packing size:720x530x1900mm
13)   units per 20-feet container::35sets
