01)  Motor: 2,200W

02)  Planing table size: 310 x 1,520mm

03)  Thicknessing table size: 310 x 750mm

04)  Cutter block diameter: 95mm

05)  Feeding block diameter: 40mm

06)  Cutting knives: four

07)  Fence tilt: 0 to 45 degrees

08)  Dust chute diameter: 100mm

09)  Maximum planing width: 310mm

10)  Maximum thicknessing width: 310mm

11)  Maximum cutting depth: 5mm

12)  Maximum thicknessing height: 220mm

13)  Cutter block speed 50Hz: 4,000rpm

14)  Cutter block speed 60Hz: 4,800rpm

15)  Feed speed 50Hz: 6m/min

16)  Feed speed 60Hz: 7.2m/min

17)  Packing size: 1,670 x 640 x 970mm

18)  Net/gross weight: 323/390kg

19)  Units per 20-foot container: 24

Optional fitting:

* Spiral cutter block with 80pcs blades optional

* NSK Bearings fitted for better performance optional

* 310x1800mm Planing table optional

* With optional high-quality 150mm height machined aluminum rear fence available.
