01)  Motor: 1,500W

02)  Planing table size: 250 x 1,050mm

03)  Thicknessing table size: 250 x 600mm

04)  Cutter block diameter: 75mm

05)  Feeding block diameter: 40mm

06)  Cutting knives: three

07)  Fence tilt: 0 to 45 degrees

08)  Dust chute diameter: 100mm

09)  Maximum planing width: 250mm

10)  Maximum thicknessing width: 250mm

11)  Maximum cutting depth: 2.5mm

12)  Maximum thicknessing height: 180mm

13)  Cutter block speed 50Hz: 4,000rpm (50Hz), 4,800rpm(60Hz)

14)  Feed speed 50Hz: 4.8m/min (50Hz), 5.8m/min(60Hz)

15)  Mortising chisel capacity: 16mm

16)  Mortising Vertival stroke: 85mm

17)  Mortising Table travel up/down: 80mm

18)  Mortising Lateral stroke: 140mm

19)  Mortising Table szie: 160x368mm

20)  Packing size: 1,150 x 530 x 950mm

21)  Net/gross weight: 171/217kg

22)  Units per 20-foot container: 44

Optional fitting

* With optional high-quality 150mm height machined aluminum rear fence available.
