01) Motor: 1,500W
02) Planning table size:250 x 1,050mm
03) Thicknessing table size: 250 x 600mm
04) Cutter block diameter: 75mm
05) Feeding block diameter: 32mm
06) Cutting knives: three
07) Fence tilt: 0 to 45 degrees
08) Dust chute diameter: 100mm
09) Maximum planing width: 250mm
10) Maximum thicknessing width: 250mm
11) Maximum cutting depth: 2.5mm
12) Maximum thicknessing height: 180mm
13) Cutter block speed 50Hz: 4,000rpm
14) Cutter block speed 60Hz: 4,800rpm
15) Feed speed 50Hz: 4.8m/min
16) Feed speed 60Hz: 5.8m/min
17) Packing size: 1140X520X750mm
18) Net/gross weight: 148/177kg
19) Units per 20-foot container: 66


Optional fitting:
* Spiral cutter block with 64pcs blades optional
* NSK Bearings fitted for better performance optional
* Cast iron fence optional
* With optional high-quality 150mm height machined aluminum rear fence available.
