C2-260S

C2-260S 10" PLANER & THICKNESS ONE PIECE SWING UP TABLE STYLE 2200W
Main Features

* New series Planer Thicknesser with Parallel Table Lift
 * Fast and easy change over from Planing to thicknessing for improved work flow.
 * Fitted with super high quality HSS blades as standard


Description Video Documents

Specifications:

01)   Motor: 2,200W
02)   Planing table size: 1050x250mm
03)   Thicknessing table size: 600x250mm
04)   Cutter block diameter: 75mm
05)   Feeding block diameter: 32mm
06)   Cutting knives: three
07)   Fence tilt: 0 to 45 degrees
08)   Dust chute diameter: 100mm
09)   Maximum planing width: 250mm
10)   Maximum thicknessing width: 250mm
11)   Maximum cutting depth: 3mm
12)   Maximum thicknessing height: 180mm
13)   Cutter block speed: 4,000rpm
14)   Feed speed: 4.8m/min
15)   Packing size: 1,150x590x950mm
16)   Net/gross weight: 170/ 206 kgs
17)   Units per 20-foot container: 36


Optional fittings:

* With front Decorative cover optional.
* With Mechanical Digital Display for thicknessing height optional.
* With Spiral cutter  and Cast Iron Handwheel as optional fitting.
