* Steel plate bed and legs
* Electronic variable speed control
* Digital spindle speed indicator
* 30°direct indexing using 1 indexing hole
* 10°indexing using all three indexing holes
* Headstock can be positioned anywehere along the bed
* 0°,45°,90°,135°,180°,270°and 360°headstock rotation
* Tailstock, headstock and tool rest support have lever action cam locks for quick positioning
* Belt drive offers 2 speed ranges
* Spindle lock pin
* Outboard spindle handle, Forward/reversing switch, Emergency stop switch
Specifications:
01) Description: 16"x42" wood lathe 02) Motor: 1100W(Input), 0.75KW(Output), 3PH, 230V
03) No.of Speed: Variable
04) Spindle Speed: 0~1200rpm Low Speed, 0~3200rpm High Speed
05) Swing Over Bed: 16"(408mm)
06) Distance Between Centers: 42"(1060mm)
07) Drive Spindle: M33X3.5 RH
08) Headstock and Tailstock Taper:MT2#
09) Face Plate: 152mm(6")
10) Tool Rest: 355mm(14")
11) Packing Size(mm): 1590x540x590
12) G/N.W: 180/151kgs
13) Units per 20-foot container: 68pcs
