The lathe is constructed from cast iron and includes a powerful 550W universal motor with electronic speed control that provides full torque at all speeds. Dial a slow speed for larger pieces and faster speeds for spindles and fine finishing. The 3-belt positions adjust from 650RPM to 3800RPM. Fitted with a digital screen to show the spindle speed.
01) Motor: 750W (550W output DC Motor)
02) Motor Step: 3
03) Spindle speed: 650-1450RPM；1250-2800RPM；1600-3800RPM
04) Swing over bed: 305mm
05) Distance between centers: 457mm(18 inches)
06) Drive spindle: 1/8-inch RH thread or other
07) Head and tailstock taper: #2 morse or other
08) Face plate: 3 inches, Tool rest: 6 inches
09) Net weight: 38kg, Gross weight: 40kg
10) Packing size: 840 x 460 x 300mm
11) Units per 20-foot container: 245
The model number for MC1218VD with extension bed is MC1239VD
