01)Motor power - main saw: 2200W

02) Motor power - spindle moulder: 1500W

03) Motor speed (rpm): 2850

SAWING:

01) Main blade size:Ф254xФ30x3.2x2.2x24T

02) Main blade speed (rpm) :4750

03) Max cutting height (mm) :80

04) Cutting height for blade 45° (mm):60

05) Main/scoring blade tilting range: DX 0～45°

06) Table size usabe for saw (mm) :1300X1850

07) Dust chute diameter - saw (mm) :100

08) Length/travel for sliding table (mm) :1300/1580

SPINDLE MOULDER:

01) Max moulder cutter diameter (mm) :19.05/30/32

02) Moulder Spindle travel:110

03) Moulder cutter speed (rpm):1400/4000/6000/8000

04) Table size usable for moulder (mm) :1300X1100

05) Max tooling dia above table (mm):150

06) Max tooling dia below table (mm):150

07) Exposed spindle length (mm):103

08) Moulder guard dust chute diameter (mm) :100

MISCELLANEOUS:

01) Packing size (mm): 1380x740x1040

02) N.G. weight without mortiser (kgs):196

03) Units/20' container:24

Optional fitting:

*  Steel round bar rip fence channel optional
