LCSET-1 REVOLVING CENTERS KIT WITH ALUMINUM BOX

1.  MT2 SHAFT length 70.5mm, with 53.5mm length x 44mm OD main bearing housing, includes triple-stacked 35mm OD bearings.

2.  60°CONE CENTRE that measures 18mm at its widest point.

3.  CUP CENTRE that measures 14mm at the smallest edge of the cup with a generous 5mm depth. The removable centre protrudes about 3.5mm from the rim of the cup.

4.  Fine CENTRE POINT that measures about 6.3mm diameter at its widest point. This adds approximartely 28.6mm to the length of the centre

5. Large CONE ATTACHMENT It has a useable supporting diameter from 18 - 45mm. The maximum diameter is approximately 50mm so this will give you a margin of safety supporting the work pieces.

6. A threaded ADAPTER SPIGOT to mount the large cone attachment.

7. KNOCKOUT BAR to quickly change applications as well as the handy storage case as shown.

Packed in Aluminum box, 5sets in one carton box

Carton box size:340*260*200 mm, N/G weight:7/8kgs
