Product Catalog

MJ12-1360E

12" SLIDING TABLE SAW WITH 1360MM SLIDING TABLE 2200W
Main Features
Description Video Documents

01)   Motor Power: 2200W(brake motor)
02)   Major Table Size:350X760 mm
03) Extension Table (Steel plate):600x760mm
04) Rear Extension Table:350X500mm
05) Sliding panel Size:1360X270mm
06) Cross Cut Table Size:680×580mm
07) Cross Cut Fence:1200-2200mm
08) Blade Size:315X30X3mm
09) Blade Speed:4250rpm(50hz),5130rpm(60hz)
10) Max Cut Depth:100mm at 90 degree(315)
11) Max Cut Depth:75mm at 45 degree(315)
12) Cutting width on rip fence:940mm
13) Cutting Length: 1220mm
14) Packing Size: (1)1000X950X1000mm,2)1450X500X160mm
15) Weight(N,W/G,W):194kg/254kg
16) Units/20'GP:20pcs
